AMT 388 Series Bronze Straight Centrifugal Pump

Bronze constructed centrifugal pumps with a maximum pressure of 75 PSI and maximum head of 62ft.

Select your options below…

{{ option.description }}
"{{ option.noLongerAvailable }}" is no longer a valid option. Please choose from the current set of options.
Need help? Call one of our pump experts at 1-802-255-4003. We’re open Mo-Th 8am to 5:30pm. Fr 8am to 5pm ET.
Starting Price: $847.00
Selected Options: + ${{ calcAdditionalCost | formatCurrency }}
${{ calcCost | formatCurrency }} per {{ calcQuantity }} per {{ boxQuantity }}
Configured Part Number: {{ calcPartNumber }}
Alternate Part Numbers: {{pn}}
{{pn}}
{{ calcAvailability }}
Request Quick Quote
Get Business Financing!
Payments as low as ${{monthlyPayments}}/mo
Product Manual
Product Specs
Highlights...
  • By AMT
  • Usually ships in 1 to 2 weeks

Features

  • Bronze construction
  • Viton mechanical seal and o-ring
  • 1 1/2in x 1 1/2in NPT thread
  • 75 PSI maximum working pressure
  • 180°F maximum working temperature
  • 62ft maximum head
  • 0.5 to 2.0 HP TEFC single phase motor
  • Pull-from-rear design
  • 1/8in maximum diameter solids handling

The AMT 388 Series is a bronze straight centrifugal pump series designed for use with most gravity fed service applications requiring liquid transfer. All models are fitted with a self cleaning stainless steel impeller for a maximum 1/8in diameter solids handling. The pumps feature a pull-from-rear design for servicing without removing piping. The motor is a 0.5 to 2.0 HP TEFC single phase motor, depending on configuration selected. Additionally, these pumps are fitted with a viton mechanical seal and o-ring. These pumps are not self-priming and require flooded suction.
